Remote desktop, GNS3 crashes when drag and drop topology objects

Couple of days ago I reinstalled my machine that I use as GNS3 server. It was about time as thing started to become a bit unstable after so many patches and updates to bring it up from Ubuntu 8.04.

I picked Xubuntu 14.04 LTS as my distro because I like XFCE and with the new GNS3 installed directly from PPA following https://www.gns3.com/support/docs/linux-installation it seems to be a piece of cake the entire story.

Unfortunately the reality was different. The above machine is sitting in my lab and most of the time I do just remote desktop on it via X2GO or XRDP. The issue that I encounter was that GNS3 was starting fine, everything looked to be working correctly, but when I was trying to drag and drop an object (like router, switch) to the topology the GNS3 would crash and the logs would show a nice segmentation fault.

I spent a lot of hours reading about and it seems I’m not the only one which had this strange behavior. However nobody could actually point out a real solution to this problem.

One workaround that I found to be working is to use Thinlinc, a remote desktop server provided by Cendio. The free version supports for up to 10 concurrent users and in my case this limitation should not pose a problem. One disadvantage can be seen that it’s not open source and you need to install also the client software. Again not a big deal, at least for my scope.

If you arrived to my post looking for a solution, the above workaround can be one and it’s working fine.

However, the engineer in me was not satisfied as why the solution would not work just using the included packages in Ubuntu 14.04 LTS.

Digging more, I found that the problem is not actually related to GNS3, but rather to the Qt version that comes with Ubuntu 14.04. Also it’s seems that not only GNS3 is affected by this issue, which appears to be a Qt Bug, but also other software used via a remote X11 connection – https://bugreports.qt.io/browse/QTBUG-38109

Now if you check the GNS3 Linux manual installation page, you’ll see that python3-pyqt5 must be installed. When you install it from PPA, the same python3-pyqt5 is installed, just that maybe you’ll miss it among the other packets that are added automatically.

Checking the Ubuntu 14.04 packages http://packages.ubuntu.com/trusty/python/ (search for python3-pyqt5 to avoid going via all packages) I noticed that the default version is 5.2.1 I’ve checked for particular Bugs with this version that can be related to my problems, unfortunately my search brought no conclusive result, so I had to assume that this version has a problem. I’m not a developer so this task was even harder for me.

I went to check the next Ubuntu release. 15.04 is out of the marked since January 2016 and the only alternative was 15.10. I’m not very keen on trying non-LTS versions, but desperate times require desperate measures. Searching for the same python3-pyqt5 (http://packages.ubuntu.com/wily/python/) I saw that this version is 5.4.2.

Next I tried to find a way to install the 5.4.2 python3-pyqt5 version on Ubuntu 14.04. No success here. I ran into more problems than solutions. If you have a solution to have these two versions working together, please let me know.

Having nothing to lose I downloaded the Xubuntu 15.10, installed it and…everything is working like a charm so farm. I can open GNS3 and drag and drop successfully via a remote connection (XRDP or X2GO).

As you can see I have no solution to the actual problem, but at least I can suggest 2-3 workarounds that may get you out of the woods. For me an article like this would have been very helpful while doing my research, but there was none out there, beside different community posts usually without any answer. This is the reason for which I wanted to share this story with you.

If you have this issue and found another solution, please let me know as I would like to use the 14.04 LTS version of Ubuntu, otherwise I need to wait for the release of 16.04 LTS scheduled for this year.

SSL Certificate signed by own CA

There are a lot of “how-to” on the Internet explaining the setup procedure. This is mainly a copy / paste example for those in a hurry :)

How to setup your own CA

Generate a key for CA

openssl genrsa -aes256 -out myCA.key 4096

Pick a password and remember it!

Generate a SSL certificate for CA

openssl req -new -x509 -days 3650 -key myCA.key -out myCA.crt

How to create a new SSL certificate signed by your own CA

Request a new key for the new domain that you want to secure

openssl genrsa -aes256 -out MyServerName.key 2048

Pick a password and remember it!

Request a CSR and sign it with the previous created key

openssl req -new -key MyServerName.key -out MyServerName.csr

Request the SSL certificate and sign it against the CA

openssl x509 -req -in MyServerName.csr -out MyServerName.crt -sha1 -CA myCA.crt -CAkey myCA.key -CAcreateserial -days 720

(Optional for Linux) Secure the key on the server

chmod 0400 *.key

To have the SSL working you need to copy on the server side
– MyServerName.key
– MyServerName.crt
– myCA.crt (that’s the CA certificate)

How to view a certificate

openssl x509 -in MyServerName.crt -text -noout

How to check whether a private key matches a certificate or that the certificate matches the certificate signing request (CSR)

openssl x509 -noout -modulus -in MyServerName.crt | openssl md5
openssl rsa -noout -modulus -in MyServerName.key | openssl md5
openssl req -noout -modulus -in MyServerName.csr | openssl md5

Does anybody knows a simple script that can offer the above functionality from web interface? I was looking around for a while now, but either they are enterprise complex or do not work. Let me know in Comments if you have a good suggestion.

Thanks!

GNS3 1.2.1 installation on Ubuntu 14.04

As mentioned in an earlier post GNS3 is moving ahead fast. Currently at version 1.2.1 the GNS3 is looking great. Compared with the version 1.0 Beta 1 which I had installed, the 1.2.1 is not only more stable, but it has the Menu more clean and compact. For example now there is only one Preferences menu where you can adjust all your settings.

During the installation of 1.0 Beta 1 I made some notes in Evernote and it prove to be very useful as the installation was pretty messy. With 1.2.1 I did the same thing, but the installation was very smooth. Still, I said that if I made those notes maybe I should share them for those interested in a quick installation. A more complete guide can be found on GNS3 Community.

1. Download GNS3 1.2.1

Head over to http://www.gns3.com/, create and account and download the bundle archive for Linux.

If you for some reason you don’t want to create an account, you may download each package individually from https://github.com/GNS3

The following lines will assume that you have the bundle archive.

2. Install Ubuntu 14.04 dependencies

$ sudo apt-get install libpcap-dev uuid-dev libelf-dev cmake
$ sudo apt-get install python3-setuptools python3-pyqt4 python3-ws4py python3-netifaces python3-zmq python3-tornado
$ sudo apt-get install unzip

3. Unzip the bundle archive

$ unzip GNS3-1.2.1.source.zip

You should see 5 packages in GNS3-1.2.1 folder:
dynamips-0.2.14.zip
gns3-server-1.2.1.zip
gns3-gui-1.2.1.zip
iouyap-0.95.zip
vpcs-0.6.zip

4. Install Dynamips

$ unzip dynamips-0.2.14.zip
$ cd dynamips-0.2.14
$ mkdir build
$ cd build
$ cmake ..
$ make
$ sudo make install

To check if the correct version is install:

$ dynamips | grep version

You should see in the output 0.2.14

5. Install GNS3 Server

$ unzip gns3-server-1.2.1.zip
$ cd gns3-server-1.2.1
$ sudo python3 setup.py install

To check if the GNS3 Server is installed correctly:

$ gns3server

If you see some output other than an error, than you’re fine.

6. Install GNS3 GUI

$ unzip gns3-gui-1.2.1.zip
$ cd gns3-gui-1.2.1
$ sudo python3 setup.py install

To test if the installation is working:

$ gns3

You should see a graphical interface of GNS3 launched.

At this moment you have a working GNS3 environment if you want only want to test Cisco hardware emulators. I strongly recommend to continue and install also the rest of the components. Who knows when you’ll need them

7. Install IOUyap (Optional, if you will use IOU images)

$ unzip iouyap-0.95.zip
$ cd iouyap-0.95.zip
$ make
$ sudo make install

To test the installation:

$ iouyap -h

If you encounter an error, please check the [Update 1] section at the bottom of this article.

8. Install VPCS (Optional, if you want to use VirtualPC)

$ unzip vpcs-0.6.zip
$ cd vpcs-0.6/src
$ ./mk.sh 64
$ cp vpcs /usr/bin/

For the third line, the 64 represent 64bit, as my Ubuntu 14.04 is build on 64bit.
The values can be:
– 32 or i386 for 32bit OS
– 64 or amd64 for 64bit OS

Please be sure to use the correct one for your OS.

To test the VPCS:

$ vpcs

You should see a Virtual PC being launched. Leave the console with letter q.

9. Install VirtualBox (Optional, if you want to launch VMs)

Download the correct version for your system from https://www.virtualbox.org/wiki/Linux_Downloads. The following lines will assume an Ubuntu 14.04 64bit OS.

$ apt-get install dkms
$ dpkg -i virtualbox-4.3_4.3.20-96996~Ubuntu~raring_amd64.deb

You can also use the instructions at https://www.virtualbox.org/wiki/Linux_Downloads and go for an APT installation.The choice is yours.

10. Install Qemu (Optional, if you want to use qemu images)

$ sudo apt-get install qemu

11. Install IOU (Optional, if you want to use IOU images)

I’m not a legal matter expert, and the usage of IOU is sort of grey area. Because of this, I’m not going to cover this chapter.

You’re ready to go. Start the GNS3 GUI:

$ gns3

Some things to check before going live:

  • check in the menu Edit > Preferences to set your desired Paths (in General sections) and to check the paths for the binaries (dynamips, vpcs, iou, virtualbox…)
  • add the IOS, virtualbox vm, iou images
  • in case of Cisco hardware emulators don’t forget to find the IdlePC value (when you add the IOS image or later with the start of your first router with a certain image) otherwise your CPUs will cry.

If something does not work as described or you need help please let me know in Comments.

[Update 1]

If you get the following error during installation of iouyap:

GNS3-1.2.2.source/iouyap-0.95 $ make
gcc -g -DDEBUG -Wall -c -o iouyap.o iouyap.c
iouyap.c:40:23: fatal error: iniparser.h: No such file or directory
#include
^
compilation terminated.
make: *** [iouyap.o] Error 1

Try to install the iniparser as follows:

sudo apt-get install flex bison

then

cd /tmp
curl -L https://github.com/ndevilla/iniparser/archive/master.tar.gz | tar -xz
cd iniparser*
make

and finally iouyap

cd /tmp
curl -L https://github.com/GNS3/iouyap/archive/master.tar.gz | tar -xz
cd iouyap*
bison -ydv netmap_parse.y
flex netmap_scan.l
gcc -Wall *.c -I /tmp/iniparser*/src -L /tmp/iniparser* -o iouyap -liniparser -lpthread
strip --strip-unneeded iouyap
sudo mv iouyap /usr/local/bin

Thanks to mweisel @ forum.gns3.net for this update!

Troubleshooting with Wireshark [Riverbed lab kit]

A while ago I attended a Wireshark webinar from Riverbed in which they presented the tool, some beginner and intermediate users troubleshooting scenarios and some lab kit.

Now I got an e-mail that they made it available for download at http://www.riverbed.com/wireshark-virtual-tour

Part of this Lab Kit were available in the Virtual World Tour 2014 webinar on Troubleshooting with Wireshark, held by Laura Chappell and Gerald Combs.

Kit is a free collection of Wireshark training, trace files and tips and tricks for troubleshooting your network. This lab kit contains the following:

  • Nine Network Analysis Training videos
  • Troubleshooting Checklist
  • Sample Network Analysis Report
  • Practice Trace Files
  • Laura’s Wireshark Troubleshooting Profile
  • Chapter Excerpts from Laura Chappell’s new book “Troubleshooting with Wireshark Locate the Source of Performance Problems”


    • If you are interested in troubleshooting with Wireshark, I think this would be a nice place to start. The presentation page of Wireshark Virtual Tour looks a little bit like comics marketing style, but the materials are pretty good.

    Live digital threats

    I wanted to bring these free tools to my blog to keep track of them, as most probably I will forget about, and to share with anybody interested in gathering information in the security areas.

    First tool was revealed to my in tweet from Greg Ferro:

    https://twitter.com/etherealmind/status/392606499044098049

    As usually I trust his words, I said to give it a try. I can tell that this tool is very interesting. According to the explanation found on http://www.digitalattackmap.com/faq/ :

    The Digital Attack Map presents data gathered and published by Arbor Networks ATLAS® global threat intelligence system. ATLAS sources its data worldwide from 270+ ISP customers who have agreed to share anonymous network traffic and attack statistics. Data is updated hourly and can also be found in Arbor’s ATLAS Threat Portal.

    Below you have an embedded version of this map, but better access the Digital Attack Map website.

    Second tool caught my attention from the Digital Attack Map explanation and it’s called Arbor’s ATLAS Threat Portal.

    Atlat Threat Portal

    This tool is explained as:

    The ATLAS portal today is a public resource that delivers a sub-set of the intelligence derived from the ATLAS sensor network on host/port scanning activity, zero-day exploits and worm propagation, security events, vulnerability disclosures and dynamic botnet and phishing infrastructures.

    If the first tool is related to network attacks, the second one is covering more topics like botnets, phishing, scans and more.
    You can access Arbor’s ATLAS Threat Portal here.
